12mm Pyroguard Firesafe T-E30 - cut to size glass
Images are for illustration purposes only.

12mm Pyroguard Firesafe T-E30

SKU: TGSO-12MMPYROGUARDFIR

Fire Rated Glass — Request a Quote

Fire rated glass is manufactured to order to your exact specification. Complete the form below and we'll come back to you with a detailed quote.

mm
mm
Processing required (optional)

Select any that apply. Suitability and pricing will be confirmed in your quotation.

Or call / WhatsApp: 07787 704925

Processing Options
Sandblasting
Request a frosted finish as part of your quotation.
Ritec ClearShield Coating
Request an easy-clean coating as part of your quotation.
Cut-outs
Describe your required cut-outs in the enquiry notes.
Request these options in the enquiry form above. Suitability and pricing will be confirmed in your quotation. For bespoke requirements, call 020 7206 2492.
Applications & Uses
Timber framed screens (E30 single glazed)
Timber fire doors (E30 single glazed)
Steel framed screens (E30 single glazed)
Steel doorsets (E30 single glazed)
Not sure if this glass type suits your application? Call our team on 020 7206 2492 for free advice.

About This Product

12mm Pyroguard Firesafe T-E30 is a toughened, modified fire-resistant float glass providing 30 minutes of integrity protection (E30 classification). The thickest standard option in the Firesafe toughened glass range, it is well-suited to large-format fire glazing applications where additional panel strength is required alongside E30 fire performance.

Technical Specifications

  • Fire Classification: E30
  • Fire Rating: 30 minutes Integrity
  • Reaction to Fire: A1
  • Thickness: 12mm
  • Glazing Type: Single
  • Grade: Internal and External
  • Standard: BS EN 13501-2 / EN 572-2

Certified Applications

  • Timber framed screens (E30 single glazed)
  • Timber fire doors (E30 single glazed)
  • Steel framed screens (E30 single glazed)
  • Steel doorsets (E30 single glazed)

Frame Compatibility

  • Steel
  • Timber

Key Features

  • E30 fire classification — 30 minutes integrity
  • Reaction to fire class A1 — completely non-combustible
  • Toughened modified float glass — maximum strength in the toughened Firesafe range
  • Very high light transmission — excellent optical clarity
  • Easily processed and fabricated — cut-outs, shapes, and custom sizes available
  • Manufactured in accordance with EN 572-2
  • Fully recyclable
  • Suitable for interior and exterior use
  • Certifire approved

Important Information

Fire-rated glass must only be used as part of an appropriately approved and tested glazing system. Installation should be carried out by FIRAS-approved specialists in accordance with the relevant Certifire certificate specifications.

  • Edge clearance: 4–5mm required
  • Lateral clearance: 4–5mm required
  • Rebate depth: minimum 20mm
  • Operating temperature range: -20°C to +40°C
  • Store in dry, ventilated conditions away from direct sunlight
  • Never allow water contact with glass edges
